Teams from all over the US, Canada and Brazil will be coming to California to fight for The ComBots Cup - the annual international robot combat championship now in its seventh year. The ComBots Cup is to fighting robots what the World Series is to baseball.
The two-day event features robots weighing up to 220 pounds fighting to be crowned the world heavyweight champion. While the recent movie "Real Steel" thrills audiences with CGI robots, the ComBots Cup promises the real thing.
At stake for competitors is not just honor and glory, but the ComBots Cup itself, a 100lb, three-foot-high trophy that comes with the biggest cash prize purse in the sport. The following robots (sorted by rank) will be fighting to the death in a double elimination ladder over the course of the two-day event.
|Team:||Late Night Racing|
|Hometown:||San Leandro, CA|
|Since the early years of the sport, Team Late Night Racing had won several events in the 60 pound category. Wanting to up the ante, Original Sin was built in 2006 with the specific goal of winning the ComBots Cup. Although it didn't win the first year out, it has since picked up seven first place finishes along the way - including four gold medals at RoboGames, before finally winning the Cup its fourth year out in 2009. Original Sin then repeated the win to keep the Cup in 2010 and again in 2011.|
Original Sin was designed to be easy to build, easy to drive, easy to repair, and relatively inexpensive to maintain. Most of the fabrication of Original Sin was done with common power tools like a jigsaw and a drill press but a few parts did require machining or welding. Its almost square stance makes it extremely stable and easy to drive. Removing the top allows easy access to all internal components so that they can be replaced if needed.
Original Sin uses robust NiCad batteries (which some consider dated tech) to power its two 4.5 horsepower motors. The motors drive the high-traction foam tires and give Original Sin the speed needed to deliver a heavy blow to its enemies with its steel wedge.
|Sewer Snake was developed using three main design principles:|
Simplicity: Team PlumbCrazy uses off the shelf components laid out as practically as possible to make the robot easy to maintain and repair. While individual fights are won or lost in the arena, the competition is won in the pits.
Mobility: Off road 4-wheeling was the inspiration for Sewer Snake's drive train. Ground clearance and over-sized exposed tires help Sewer Snake get off of other robots or arena debris. The 6-wheel design has redundancy which helps maintain mobility, so that even when Sewer Snake loses tires, it keeps on going.
Modularity: Since robot combat is like a game of "Rock/Paper/Scissors", a modular design helps the robot to be more than just "a rock." Sewer Snake uses trailer hitch material to mount the variety of weapons and armor that are used against different types of opponents, which makes for quick change of weapons between fights.
While following these basic principles, Sewer Snake still knows how to have fun. Over time, Sewer Snake has evolved into the animated, fire-breathing, break-dancing, red-tired beast that loves put on a show. The audience agrees!
|With a 50lbs vertical blade of spinning death and hardened AR400 steel wedges, The Electric Boogaloo is aiming show the opponents what's up by breakdancing the competition into the rafters. The Electric Boogaloo is a combination of designs that both Orion Beach and Dan Chatterton had built in smaller weight classes. It is an effort to build the perfect vertical spinning weapon robot powered by a motor meant to drive small electric cars, it can impact an opponent at over 200 mph. |
Orion has put forth many of his own talents into this project. He is excellent at 3D modeling and coming up with offensive and defensive geometry. The shape of the blade and front armor both originate from his 3-pound beetleweight robot Gouge. He also came up the rock-solid mounting methods for the weapon system. Having a background in RC Cars, Orion knows how to choose the most reliable parts.
Dan is a bit more chaotic, with a philosophy that that the weapon always has to be bigger, spin faster, and hit harder. Dan has a good grasp on how all of the electronics works, as well as how to protect the robot against itself.
|Currently the kinetic energy king of the combat robotics world, Last Rites is a machine that is both feared and admired. Always a crowd favorite, Last Rites routinely destroys everything in its path which sometimes includes the arena!|
Last Rites is constructed from welded tubular chrome-moly steel, and weighs in at 218 pounds. The spinning bar alone weighs 75 pounds, which spins at 2200 rotations per minute. Using cutting edge battery technology and one of the most powerful DC motors there is, Last Rites is always a front-runner at every event in which it competes. When Last Rites enters the arena, destruction follows!
During RoboGames 2010, Last Rites proudly caused more damage to the combat arena (in both monetary and visible damage) than all other robots combined!
Last Rites is a returning ComBots Cup champion, having won the title in 2008. Look for Last Rites and driver Ray Billings to make a serious run at regaining the title this year!
|Ragin Scotsman is a heavy weight robot built by a joint effort from Piedmont High school's robotics club "Scotbotics" and veteran team Robomaster. Robomaster has competed at many events, and while this is their first heavyweigth robot, they have many 1st place finishes in the smaller weight classes to show for their efforts.|
Raging Scotsman is wrapped with a shock-mounted steel wedge that weighs over 45 pounds. It uses a flamethrower, designed to cook and intimidate its foes.
Its dual driver/weapon operation is just another way this robot "teams up" against the competition.
Ragin Scotsman's drive motors and tires were donated by ComBots help complete this rookie bot and keep it underbudget.
|Robot:||Vlad the Impaler II|
|Driver:||Vlad the Inhaler|
|Hometown:||Mill Valley, CA|
|Vlad the Impaler II is a menacing lifter with one of the most powerful drive-trains in the sport. Powered by two LEMCO brushed motors, Vlad generates 8 Kilowatts (10.7 horsepower) in its drive train. The lifter is driven by a powerful 2.24 Kilowatt (3 HP) AmpFlow motor which is fully capable of lifting another 100 kg (220 pound) robot and dragging it across the arena floor. |
Vlad's armor is completely independent of the inner frame and drive train, and this gives the robot a tremendous advantage when taking damage - any damaged plates can quickly be replaced without any cutting, welding, or major disassembly. Rubber shock mounts isolate the primary frame from the titanium and lexan outer shell, so even when Vlad gets thrown around by an opponent, the inner frame remains undamaged.
On several occasions, Vlad has slammed at full speed into Last Rites, and even though the primary armor was destroyed, Vlad's internal drive-train took no critical damage. The incredible 4QD speed controllers can easily source up to 300 amps without ever losing their "magic smoke." Vlad was originally designed by Gage Cauchois, and rebuilt and extensively modified by David Calkins.
|Displaying the spirit of Halloween, the Great Pumpkin smiles sinisterly at all opponents. |
Sporting a huge steel wedge which hides a flame-thrower, backed by a powerful drive train, the Great Pumpkin looks to get under its opponents and dominate through shear pushing power.
The Great Pumpkin is constructed of a welded tubular steel frame, which supports the large steel wedge up front. The wedge is 3/8" thick, designed to take on the opponent's weapons, and then ask for more.
The drive train consists of a pair of wheelchair motors driving foam filled go-cart tires. This is a simple but effective design, and the Great Pumpkin looks to make every event worthy of Halloween!
|Hometown:||Liberty Hill, TX|
|Blizzard is Team Toad's all new heavyweight for ComBots Cup 2011: a culmination of Fuzzy's 12 years of robot combat experience.|
Blizzard's 3/16" 6061 aluminum unibody was actually manufactured 10 years ago as a spare for Team Toad's 2001 heavyweight. But new technology means Blizzard has 13% more battery capacity, is 38% faster and has double the horsepower of its predecessor. The spinning weapon weighs 20% less than the earlier thresher, but stores 4 times as much kinetic energy.
Blizzard's 10" flat-proof rubber tires provide superior traction on the debris-filled combat arena floor. The knobby tire pattern sheds dirt and metal better than slick tires. Heavier tires mean larger shock forces when hitting solid objects, so each titanium drive axle has a spring-clutch that slips during high shock loads, protecting the motors from impact forces.
The biggest change is Blizzard's weapon: 40 pounds of spinning P20 tool steel 9" in diameter and 2.5" thick. A 5 HP AmpFlow motor spins the disc over 4,000 rpm -- so rapidly that gyroscopic forces flip Blizzard up on two wheels if it turns sharply to the right. The weapon motor also has a spring clutch on its chain drive, decoupling the motor during impacts.
|Robot:||Son of Ziggy|
|Hometown:||Ottawa, ON, Canada|
|New to the ring, Son of Ziggy is fighting not only the other robotic gladiators, but also fighting to emerge from the shadow of his papa, Ziggy. While many know of Ziggy's five year reign as the super heavyweight champion, Son of Ziggy is just starting to carve his place his history.|
A robot from CM Robotics with engineering by Nuvation, Son of Ziggy follows in the footsteps of Ziggy, Texas Heat, CycloneBot, and BravePart. A pneumatic flipper like his papa, Son of Ziggy is nitrogen-based with a primary carbon fiber tank at 4500psi. Titanium armor is worn over a magnesium chassis with Lithium batteries.
Little is known of the relationship between Ziggy and Son of Ziggy. The son has shown some of the talents of his papa, but some say Ziggy thinks his son is impetuous and needs to find his center. Son of Ziggy has taken to pulling Ziggy off his name and calls himself "SoZ". Rumor has it there was an explosive disagreement and Ziggy threw SoZ out of the shop! Time will show if SoZ can step up to his father's high expectations.
|Team:||University of South Florida|
|Hometown:||Tarpon Springs, FL|
|Gruff is an electrically powered lifter on a six-wheel drive base with ultra high-strength alloy steel front and corner armor. The angled armor on the corners is designed to deflect weapons away from the flexible side and rear armor.|
With six wide wheels and gum rubber tread, the robot is maneuverable enough to keep the front armor facing its opponent while still having good traction. Gruff has a top speed of 17 feet per second.
The lifting mechanism is used to lift the opponent's wheels off the ground or pin them on the arena barrier. The final stage of the lifting mechanism uses nylon straps to control the rotation of the arm. This system absorbs impacts, protecting the motor and gearbox, while also providing a tremendous amount of reduction in a small space.
Gruff was partially funded by a grant from the University of South Florida Office of Undergraduate Research. We would also like to acknowledge support from the USF Department of Mechanical Engineering, The Robotics Interest Group at USF, and Magnum Steel Services Corporation.
|Hometown:||San Francisco, CA|
|Mosquito started life in 2001 as part of the 340 pound total, 3-robot multi-bot: The Swarm. Stephen Felk, Jim Smentowski and Paul Mathis liked the idea of instilling chaos, so they built a team of three robots which fought as a single team. Outside of The Swarm, Mosquito alone weighed under 120 pounds. Though their record was nothing to speak of, the craziness of three small machines going after one large one was a huge audience favorite. Swarm vs. Final Destiny remains to this day one of the most memorable fights ever.|
Mosquito now finds itself out on its own from the complete Swarm - it fought a few times in Los Angeles at a Sun Micro Systems show in San Francisco, and has had a long career as a demo bot, fighting innumerable "grudge matches" and doing countless education show and tells.
Builder Stephen Felk decided to have a little fun and increase the armor and fight it as a 220. Originally built to handle 340s, the thinking is: "220s: piece of cake." It remains to be seen.
Mosquito is as simple as they come, it has an AR400 wedge in front, two motors, 4 batteries, a radio and a speed controller. It's fast, loud, tough, and barely under control - everything you want in a fighting robot!
